Autel Robotics EVO Max 4T XE Bundle for EVO Nest
$10,676.29
In Stock
- For Autel Robotics EVO Nest
- Fusion Light 4T XE Multi-Sensor Camera
- 8K Images & 4K Video Capture
- Thermal Imaging & Laser Rangefinder
Tracked ShippingRates shown at checkout
60-Day ReturnsOn eligible items
Expert SupportReal people, real advice
Autel Robotics EVO Max 4T XE Bundle for EVO Nest
Designed for creators who demand more from their gear, the Autel Robotics EVO Max 4T XE Bundle for EVO Nest delivers capable, consistent performance.
Highlights
- For Autel Robotics EVO Nest
- Fusion Light 4T XE Multi-Sensor Camera
- 8K Images & 4K Video Capture
- Thermal Imaging & Laser Rangefinder
Every order from NIXTRONIC ships tracked worldwide and is covered by our 60-day return policy on eligible items.
In the Box
- Autel Robotics EVO Max 4T XE Bundle for EVO Nest
- Fusion Light 4T XE Gimbal Camera
- Stand for EVO Nest
- Smart Controller V3
- Rugged Case
- Pair of Spare Propellers
- Flight Battery
- Battery Charger
- RC Charger
- 64GB SD Card
- Gimbal Cover
- Data Cable
- RC Charging Cable
- Smart Controller Cover
- Pair of Spare Smart Controller Joysticks
- Smart Controller Lanyard
| SKU | 102003219 |
|---|---|
| Brand | Autel Robotics |
| Maximum Horizontal Speed | 51 mph / 82.8 km/h |
|---|---|
| Maximum Ascent Speed | 17.9 mph / 29 km/h |
| Maximum Descent Speed | 13.4 mph / 22 km/h |
| Maximum Wind Resistance | 27 mph / 43 km/h |
| Maximum Take-Off Altitude | 2.5 Miles / 4 km |
| Maximum Flight Time | 42 Minutes |
| Maximum Hover Time | 38 Minutes |
| Maximum Tilt Angle | 35° |
| Hovering Accuracy | Vision Positioning Vertical: ±0.3' / 0.1 m Horizontal: ±1' / 0.3 m RTKVertical: ±0.49' / 0.15 m GNSSVertical: ±1.6' / 0.5 m Horizontal: ±1.6' / 0.5 m |
| Maximum Angular Velocity | 300°/s (Pitch)120°/s (Yaw) |
| Rotor Configuration | Quadcopter |
|---|---|
| Propeller Size | 11" |
| Remote ID | No |
| Aircraft I/O | 1x Micro-USB (Data)1x USB-C (Service) |
| Operating Conditions | -4 to 122°F / -20 to 50°C |
| Number of Cameras | 3 (Cannot Be Used Simultaneously) |
|---|---|
| Camera System | Wide48 MP, 1/2"-Type CMOS Sensor with 24mm-Equivalent, f/2.8 Lens (83.5° FoV) Zoom48 MP, 1/2"-Type CMOS Sensor with 64 to 234mm-Equivalent, f/2.8 Lens (40 to 10.3° FoV) Thermal Vanadium Oxide (VOX) Sensor with -4 to 1022°F / -20 to 550°C Measurement Range with 9.1mm-Equivalent, f/1 Lens (64° FoV) |
| Zoom | Zoom160x Optical Thermal16x Optical |
| Minimum Focus Distance | Wide4.9' / 1.5 m Zoom6.6' / 2 m Thermal7.2' / 2.2 m |
| ISO Sensitivity Range | Wide Photo: 100 to 6400 in Auto Mode Video: 100 to 64,000 in Auto Mode Photo: 100 to 12,800 in Manual Mode Video: 100 to 6400 in Manual Mode Zoom100 to 6400 in Auto Mode100 to 12,800 in Manual Mode |
| Night Vision | No |
| Shutter Speed | Wide 1/8000 to 8 Seconds (Photo) 1/8000 to 1 Second (Video) Zoom 1/8000 to 8 Seconds (Photo) 1/8000 to 1 Second (Video) |
| Maximum Video Resolution | Wide Up to UHD 4K at 30 fps Zoom Up to 4000 x 3000 at 30 fps Thermal Up to 640 x 512 at 30 fps |
| Still Image Support | Wide Up to 50.3 MP (JPEG) Up to 12.6 MP (DNG) Up to 12 MP (JPEG) Zoom Up to 48 MP (JPEG) Up to 12 MP (DNG / JPEG) Thermal Up to .3 MP (JPEG) |
| Media/Memory Card Slot | In Aircraft BodymicroSD/microSDHC/microSDXC |
| Internal Storage | In Aircraft Body128 GB |
| Number of Axes | Three: Pitch (Tilt) / Roll / Yaw (Pan) |
|---|---|
| Rotation Range | Mechanical Range Yaw (Pan): 180° (-135 to 45°) Roll: 90° (-45 to 45°) Pitch (Tilt): 90° (-45 to 45°) |
| Follow Speed | 100°/s |
| Stabilization Accuracy | ±0.005° |
| Sensing System | Omnidirectional with Radar Enhancement |
|---|---|
| Sensing System Capabilities | Forward Detection Range: 2 to 102' / 0.5 to 31 m Field of View: 60° (Horizontal) / 80° (Vertical) Backward Detection Range: 2 to 82' / 0.5 to 25 m Lateral Detection Range: 2 to 85' / 0.5 to 26 m Upward Detection Range: 1 to 85' / 0.2 to 26 m Field of View: 120° (Front-to-Back) / 180° (Side-to-Side) Downward Detection Range: 1 to 75' / 0.3 to 23 m Field of View: 120° (Front-to-Back) / 180° (Side-to-Side) |
| Control Method | Included Transmitter |
|---|---|
| Transmission System | Proprietary• Frequencies: 2.4 GHz (2.400 to 2.4835) / 5.1 GHz (5.150 to 5.250) / 5.8 GHz (5.725 to 5.850)• Power at 0.9G: 20 d Bm (CE/FCC)• Power at 2.4G: 17 d Bm (FCC)• Power at 5.1G: 17 d Bm (FCC) / 14 d Bm (CE) |
| Maximum Operating Distance | 9 Miles / 15 km |
| Clean Video Output | Not Specified by Manufacturer |
| Battery Type | Built-In Lithium-Ion (5800 m Ah) |
| Operating Temperature | -4 to 104°F / -20 to 40°C |
| Mobile App Compatible | No |
| Built-In Display | 7.9" (2048 x 1536) Touchscreen LCD |
| Battery Chemistry | Lithium-Ion Polymer (LiPo) |
|---|---|
| Battery Capacity | 8070 m Ah / 120 Wh |
| Battery Configuration | 4 S / 14.88 V |
| Charging Temperature | 41 to 113°F / 5 to 45°C |
| Weight | 18 oz / 520 g |
| GNSS Support | GPS, GLONASS, Bei Dou, Galileo |
|---|---|
| Diagonal Size | 1.5' / 464 mm |
| Overall Dimensions | 22.1 x 5.8 x 25.6" / 562.0 x 147.0 x 651.0 mm (Unfolded)10.1 x 5.2 x 5.7" / 257.0 x 131.0 x 145.0 mm (Folded) |
| Weight | 4 lb / 1890 g (Takeoff)4 lb / 1640 g (With Battery, Gimbal) |
