Sony HDC-F5500V Super 35mm UHD 4K Camera Head with Variable ND Filter
$68,640.00
In Stock
- Super 35 4K CMOS Sensor, Shallow DOF
- 1080p50/59.94 | Optional UHD 4K & HFR
- Crisp Global Shutter, ARRI PL Mount
- Variable ND Filter, Requires License
Tracked ShippingRates shown at checkout
60-Day ReturnsOn eligible items
Expert SupportReal people, real advice
Sony HDC-F5500V Super 35mm UHD 4K Camera Head with Variable ND Filter
The Sony HDC-F5500V Super 35mm UHD 4K Camera Head with Variable ND Filter brings serious imaging performance to every shoot, from planned sessions to spontaneous moments. At its core is a 8.3 Megapixel Super35 sensor paired with the ARRI PL lens mount.
Highlights
- Super 35 4K CMOS Sensor, Shallow DOF
- 1080p50/59.94 | Optional UHD 4K & HFR
- Crisp Global Shutter, ARRI PL Mount
- Variable ND Filter, Requires License
Ordered from NIXTRONIC, it ships with full tracking worldwide and is backed by our 60-day returns on eligible items.
In the Box
- Sony HDC-F5500V Super 35mm UHD 4K Camera Head with Variable ND Filter
- Cable Clamp Belt
- 2 x Screw (B3x8)
- Viewfinder Slide Unit
- Handle Clamp
Videos
| SKU | HDC-F5500V |
|---|---|
| Brand | Sony |
| Lens Mount | ARRI PL |
|---|---|
| Lens Communication | Yes |
| Image Sensor | Super35 CMOS |
| Sensor Resolution | 8.3 Megapixel (3840 x 2160) |
| Built-In ND Filter | Mechanical Filter Wheel with Clear ND Filters and a 1 to 8 Stop Electronic ND Filter |
| Built-In CC Filter | No |
| Broadcast System Compatibility | NTSC, PAL |
| Shutter Type | Electronic Global Shutter |
|---|---|
| Signal-to-Noise Ratio | -62 dB |
| Precise Scan Rate Control | No |
| Sensitivity | f/10 at 2000 lux 89.9% Reflectance (1080 59.4p)f/11 at 2000 lux 89.9% Reflectance (1080 50p) |
| Focus Mode | Automatic, Manual Focus |
|---|
| Internal Recording | No |
|---|---|
| Video Output | via SDI/BNC3840 x 2160p at 50/59.94 fps 1920 x 1080p at 50/59.94 fps |
| Broadcast Output | NTSCPAL |
| IP Streaming | Yes |
| Media/Memory Card Slot | No |
|---|---|
| Internal Storage | No |
| CCU I/O | 1x LEMO SMPTE |
| Audio I/O | 2x XLR 3-Pin Mic/Line Input 2x XLR 5-Pin Intercom Input/Output 1x 1/8" / 3.5 mm TRS Stereo Headphone Output |
| Power I/O | 1x XLR 4-Pin (10.5 to 17VDC) Input 1x XLR 4-Pin (10.5 to 17VDC at 0.5 A) Output 1x Light 2-Pin (10.5 to 17VDC at 2.5 A) Output |
| Other I/O | 1x 12-Pin Data 1x 20-Pin Viewfinder Output 1x BNC Test 1x BNC (Genlock, Sync) 1x 6-Pin Control 1x DIN 8-Pin Control 1x 12-Pin Data 1x 12-Pin 1x USB-A Data 1x RJ45 (Ethernet) |
| Global Positioning (GPS, GLONASS, etc.) | No |
| Display Type | No |
|---|
| Operating Conditions | -4 to 113°F / -20 to 45°C |
|---|---|
| Storage Conditions | -4 to 140°F / -20 to 60°C |
| Shoe Mount | No |
|---|---|
| Tripod Mount | 1x VCT-14 |
| Weight | 11.62 lb / 5 kg (Body Only) |
