Bolin Technology R9-L420N Large-Sensor UHD 4K NDI PTZ Camera with 20x Zoom
$6,895.00
In Stock
- 50MP Large-Format 1" CMOS Sensor
- Up to UHD 4K60 via 12G-SDI, HDMI 2.0, IP
- Full NDI, NDI|HX3, H.264/265 Compression
- USB Recording, Optional Optical SFP SDI
Tracked ShippingRates shown at checkout
60-Day ReturnsOn eligible items
Expert SupportReal people, real advice
Bolin Technology R9-L420N Large-Sensor UHD 4K NDI PTZ Camera with 20x Zoom
The Bolin Technology R9-L420N Large-Sensor UHD 4K NDI PTZ Camera with 20x Zoom is built for photographers and creators who want dependable, professional results. At its core is a 50 Megapixel 1"-Type sensor. Everyday handling is covered with No connectivity.
Highlights
- 50MP Large-Format 1" CMOS Sensor
- Up to UHD 4K60 via 12G-SDI, HDMI 2.0, IP
- Full NDI, NDI|HX3, H.264/265 Compression
- USB Recording, Optional Optical SFP SDI
Ordered from NIXTRONIC, it ships with full tracking worldwide and is backed by our 60-day returns on eligible items.
In the Box
- Bolin Technology R9-L420N Large-Sensor UHD 4K NDI PTZ Camera with 20x Zoom
- Power Adapter
- Power Cable
- IR Remote
- RS-422 Adapter Cable
- 3 x Screw
- Installation Lock
| SKU | R9-L420N |
|---|---|
| Brand | Bolin Technology |
| Image Sensor | 1"-Type CMOS |
|---|---|
| Sensor Resolution | 50 Megapixel (3840 x 2160) |
| Focus Control | Autofocus Manual Focus |
| Shutter Speed | 1/100 to 1/25 Second |
|---|---|
| Signal-to-Noise Ratio | 50 dB |
| Minimum Illumination | 0.5 Lux at f/2.8 Aperture |
| Flip / Mirror Support | Image Flip, Mirror (Vertical) |
| White Balance | Presets: ATW, Auto, Indoors, Manual, One Push Set, Outdoors |
| Focal Length | 9.8 to 196mm |
|---|---|
| Max Optical Zoom | 20x |
| Max Digital Zoom | 16x |
| Field of View | Horizontal: 71.28 to 4.08°Vertical: 40.22 to 2.16° |
| Maximum Aperture | f/2.8 to 4.5 |
| Minimum Focus Distance | 3.9" / 10 cm (Wide) to 7.9" / 20 cm (Tele) |
| Video Output | via USB3840 x 2160p at 60.00 fps 3840 x 2160p at 60.00 fps 1920 x 1080p up to 60.00 fps 4:2:2/4:2:0 10/12-Bit via HDMI / RJ45 / SDI/BNC3840 x 2160 at 23.98/24.00/25/29.97/50/60.00 fps 3840 x 2160p at 23.98/24.00/25/29.97/50/59.94/60.00 fps 1920 x 1080p at 23.98/24.00/25/29.97/50/59.94/60.00/100/120 fps 1920 x 1080i at 50/60.00 fps 1280 x 720 at 50/60.00 fps |
|---|---|
| Embedded Audio | HDMI/LAN (RJ45)/NDI/SDI |
| Internal Recording | No |
| Audio Recording | 2-Channel 16-Bit 48 k Hz AAC LC Audio |
| Broadcast Output | NTSC/PAL |
| Supported Protocols | Camera ControlIP/IR/NDI/NDI/HX3 |
| IP Streaming | H.264/H.265/MJPEG via NDI/RTMP/RTP/RTSP/TCP/UDP 3840 x 2160 at 25p, 30p, 60p (Simultaneous Multi-Stream) 1920 x 1080 at 25p, 30p, 50p, 60p (Simultaneous Multi-Stream) 1280 x 720 at 50p, 60p (Simultaneous Multi-Stream) H.264/H.265/MJPEG/MPEG-4 via NDI/NDI HX3/RTMP/RTP/RTSP 1280 x 720 to 3840 x 2160 up to 60p (Main Stream) 352 x 228 to 1280 x 720 up to 60p (Sub Stream) |
| Presets | 255 via IP, IR |
|---|---|
| Pan/Tilt/Roll | Pan: 340° (-170 to 170°) at 0.05 to 70°/s Tilt: 210° (-30 to 180°) at 0.05 to 70°/s |
| Tally Light | Yes |
| Wireless | No |
|---|
| Video I/O | 1x HDMI 2.0 Output 2x BNC (12G-SDI) Output 1x RJ45 (NDI) Input/Output 1x USB-C 3.0 / 3.1/3.2 Gen 1 Output |
|---|---|
| Audio I/O | 1x 1/8" / 3.5 mm TRS Stereo Mic/Line Input 1x 10-Pin Hirose Mic/Line Input (+48 V Phantom Power) |
| Other I/O | 1x BNC (Genlock) Input 1x BNC (Timecode) Input 1x RJ45 (RS-422) Control |
| Expansion Slots | 1x SFP+ Slot |
| Built-In Microphone | No |
| PoE Support | Yes: PoE++ 802.3bt |
|---|---|
| Power I/O | 1x Barrel (12VDC) Input |
| Power Consumption | PoE: 12 VDC 38 to 42 W |
| Operating Conditions | 14 to 122°F / -10 to 50°C up to 80% Humidity |
|---|
| Mounting | 1x 1/4"-20 Female |
|---|---|
| Dimensions (W x H x D) | 7.9 x 10.6 x 10" / 200 x 270 x 253 mm |
| Weight | 10 lb / 4.45 kg (Body Only) |
