Bolin Technology D2-220H Dante AV-H PTZ Camera with 20x Optical Zoom (Black)
$1,195.00
In Stock
- Dante AV-Enabled PTZ IP Camera
- HDMI/SDI/USB/Dante AV IP up to 1080p60
- 1/2.8" CMOS Sensor, 2.13MP
- 20x Optical, 16x Digital Zoom
Tracked ShippingRates shown at checkout
60-Day ReturnsOn eligible items
Expert SupportReal people, real advice
Bolin Technology D2-220H Dante AV-H PTZ Camera with 20x Optical Zoom (Black)
Designed for creators who demand more from their gear, the Bolin Technology D2-220H Dante AV-H PTZ Camera with 20x Optical Zoom (Black) delivers capable, consistent performance. At its core is a 2.13 Megapixel 1/2.8"-Type sensor. Everyday handling is covered with No connectivity.
Highlights
- Dante AV-Enabled PTZ IP Camera
- HDMI/SDI/USB/Dante AV IP up to 1080p60
- 1/2.8" CMOS Sensor, 2.13MP
- 20x Optical, 16x Digital Zoom
Ordered from NIXTRONIC, it ships with full tracking worldwide and is backed by our 60-day returns on eligible items.
In the Box
- Bolin Technology D2-220H Dante AV-H PTZ Camera with 20x Optical Zoom (Black)
- IR Remote Control
- Power Adapter
- Power Cable
- HDMI Cable Mount
- RJ45 to RS-232 8-Pin Control Cable Adapter
- RJ45 to RS-422 Serial Control Cable Adapter
- Set of Screws
| SKU | D2-220H |
|---|---|
| Brand | Bolin Technology |
| Image Sensor | 1/2.8"-Type CMOS |
|---|---|
| Sensor Resolution | 2.13 Megapixel (1920 x 1080) |
| Focus Control | Autofocus Manual Focus |
| Shutter Speed | 1/10000 to 1 Second |
|---|---|
| Signal-to-Noise Ratio | 50 dB |
| Minimum Illumination | 0.5 Lux (Color) |
| Flip / Mirror Support | Image Flip, Mirror (Vertical) |
| White Balance | Presets: ATW, Auto, Indoors, Manual, One Push Set, Outdoors |
| Focal Length | 5.2 to 104mm |
|---|---|
| Max Optical Zoom | 20x |
| Max Digital Zoom | 16x |
| Field of View | Horizontal: 55.8 to 3.2° |
| Maximum Aperture | f/1.6 to 3 |
| Minimum Focus Distance | 0.4" / 1 cm |
| Video Output | via RJ45 / USB1920 x 1080p at 25/30.00/50/60.00 fps 1280 x 720 at 25/30.00/50/59.94/60.00 fps 4:2:2 8-Bit via HDMI / SDI/BNC1920 x 1080p at 25/29.97/30.00/50/59.94/60.00 fps 1280 x 720 at 25/30.00/50/59.94/60.00 fps |
|---|---|
| Embedded Audio | HDMI/LAN (RJ45)/SDI |
| Internal Recording | No |
| Broadcast Output | NTSC/PAL |
| IP Streaming | H.264/MJPEG via Dante AV-H/RTMP/RTP/RTSP/TCP/UDP 1280 x 720 to 1920 x 1080 at 25p, 30p, 50p, 60p (Simultaneous Multi-Stream) |
| Presets | 255 via IP, RS-232, VISCA6 via IR |
|---|---|
| Pan/Tilt/Roll | Pan: 340° (-170 to 170°) at 0.05 to 100°/s Tilt: 120° (-30 to 90°) at 0.05 to 50°/s |
| Tally Light | Yes |
| Wireless | No |
|---|
| Video I/O | 1x HDMI 2.0 Output 1x RJ45 (Dante) Output 1x BNC (3G-SDI) Output 1x USB-C 2.0 Output |
|---|---|
| Audio I/O | 1x 1/8" / 3.5 mm TRS Stereo Mic/Line Input |
| Other I/O | 1x RJ45 (Pelco-D, Pelco-P, RS-422, VISCA) Control Input 1x USB-A Input |
| Built-In Microphone | No |
| PoE Support | Yes: PoE+ 802.3at |
|---|---|
| Power I/O | 1x Barrel (12VDC) Input |
| Power Consumption | Device: 10 to 13 WPower Supply: 12 VDC at 4 A |
| Operating Conditions | 14 to 122°F / -10 to 50°C up to 80% Humidity |
|---|
| Mounting | 1x 1/4"-20 Female |
|---|---|
| Materials | Magnesium Alloy |
| Dimensions (W x H x D) | 6.3 x 5.6 x 5.6" / 16.1 x 14.3 x 14.3 cm |
| Weight | 3 lb / 1.5 kg (Body Only) |
| Package Weight | 6.025 lb |
|---|---|
| Box Dimensions (Lx WxH) | 11.5 x 9.3 x 8.6" |
